型號
Model
|
SM-30-30 |
|
操作電壓
Connection voltage
|
380V |
|
電機總功率
Total motor power
|
24KW |
|
送料速度
Feed speed
|
0.1-1.5m/min |
|
鋸框行程
Stoke of frame
|
240mm |
|
鋸框運動次數
Number of strokes
|
450number/min |
|
最大鋸切直徑
Maximun cutting diameter
|
φ300mm |
|
最小鋸切直徑
The minimum cutting diameter
|
φ80mm |
|
木條長度
Length of wood
|
≥1000mm(木材長度可定做) |
|
鋸條數量
Number of saw blades
|
22 |
|
吸塵口
Suction inlet
|
3×100mm |
|
每個接口的吸塵數據
Vacuum data perinterface
|
1300立方/小時 |
|
壓縮空氣
Compressed air
|
≥6ba |
|
規格（長×寬×高）
Dimensions(Leng×width×heigh)
|
6000×1500×2500mm |
|
凈重
Net Weight
|
3800kg |
